GFK-1504K Chapter 5 Interposing Terminals and Auxiliary I/O Terminal Strips 5-5

IC200CHS012

Box-Style Interposing I/O Terminals

Din Rail Mounting

The Interposing I/O Terminals unit can be mounted on the same DIN rail as the

Connector-Style I/O Carrier, or on a separate DIN rail as illustrated below. For

applications requiring maximum resistance to mechanical vibration and shock, the

Interposing I/O Terminals unit must also be panel-mounted. See chapter 2 for installation

instructions.
