GE VersaMax User Manual

GFK-1504K Chapter 5 Interposing Terminals and Auxiliary I/O Terminal Strips 5-17
5
Main Base, IC200CHS111
Expansion Base, IC200CHS112
Relay-Style Interposing I/O Terminals
Relay Specifications
The field-replaceable, form-C relay used in IC200CHS111 and IC200CHS112 is
manufactured by Omron Electronics (part number G2R-14). The relay has the following
specifications:
Contact Ratings
Number of Poles 1 Pole
Load
Resistive Load (cosΦ = 1)
Inductive Load
(cosΦ = 0.4, L/R = 7ms)
Rated Load 8A at 250VAC
8A at 30VDC
6A at 250VAC
4A at 30VDC
Rated Carry Current 8A
Max Switching Voltage 380VAC, 125VDC
Max Switching Current 8A
Max Switching Power 2,000VA, 240W 1,500VA, 120W
Min Permissible Load 100mA at 5VDC
Characteristics
Contact Resistance
30 mΩ max
Operate (set) Time 15 ms max
Release (reset) Time AC: 10 ms max; DC: 5ms max
Max Operating
Frequency
Mechanical:
Electrical:
18,000 operations/hr
1,800 operations/hr (under rated load)
Insulation Resistance
1,000 MΩ min (at 500VDC)
Dielectric Strength 5,000 VAC, 50/60 Hz for 1 min between coil and contact
1,000 VAC, 50/60 Hz for 1 min between contacts of the same polarity
Vibration Resistance Destruction:
Malfunction:
10 to 55Hz, 1.5mm double amplitude
10 to 55Hz, 1.5mm double amplitude
Shock Resistance Destruction:
Malfunction:
1,000 m/s
2
200 m/s
2
when energized; 100 m/s
2
when not
energized
Life Expectancy Mechanical:
Electrical
20,000,000 operations min (at 18,000 ops/hour)
100,000 operations min (at 1,800 ops/hr under
rated load)
Ambient Temperature Operating:
Storage:
-40
˚C to 70˚C (with no icing)
-40
˚C to 70˚C (with no icing)
Ambient Humidity Operating:
Storage:
35% to 85%
35% to 85%
