GFK-1504K Chapter 1 Introduction 1-17

Communications Modules

Communications modules provide additional flexibility for VersaMax systems.

These communications modules install on a VersaMax Communications Carrier. Power for the

communications module comes from the main system power supply or from a booster supply as

shown below.

VersaMax PLC CPU

power supply

Optional booster

power supply

Profibus Network

Slave Module

Available VersaMax PLC Communications Modules

The following VersaMax PLC communications modules are available:

Communications Modules

Profibus-DP Network Slave Module IC200BEM002

DeviceNet Network Control Module IC200BEM103

Asi Network Master Module IC200BEM104

Communications Carrier IC200CHS006

For information about the Communications Carrier, please see chapter 4.
