GFK-1504K D-1
I/O Module Keying Summary
The following table summarizes keying for I/O modules:
Catalog
Number
Module Keycode
IC200ALG230
Analog Input Module,12 Bit Voltage/Current 4 Channels
D2
IC200ALG240
Analog Input Module, 16 Bit Voltage/Current, 1500VAC Isolation, 8
Channels
C7
IC200ALG260
Analog Input Module, 12 Bit Voltage/Current 8 Channels
D2
IC200ALG261
Analog Input Module, 15 Bit Voltage Differential 8 Channels
G3
IC200ALG262
Analog Input Module, 15 Bit Current Differential 8 Channels
G2
IC200ALG263
Analog Input Module, 15 Bit Voltage 15 Channels
G3
IC200ALG264
Analog Input Module, 15 Bit Current 15 Channels
G2
IC200ALG320
Analog Output Module, 12 Bit Current, 4 Channels
B8
IC200ALG321
Analog Output Module, 12 Bit Voltage 0 to 10VDC 4 Channels
D6
IC200ALG322
Analog Output Module, 12 Bit Voltage -10 to +10VDC 4 Channels
E3
IC200ALG325
Analog Output Module, 13 Bit Voltage 8 Channels
G6
IC200ALG326
Analog Output Module, 13 Bit Current 8 Channels
G7
IC200ALG327
Analog Output Module, 13 Bit Voltage 12 Channels
G6
IC200ALG328
Analog Output Module, 13 Bit Current 12 Channels
G7
IC200ALG331
Analog Output Module, 16 Bit Voltage/Current, 1500VAC Isolation,
4 Channels
D7
IC200ALG430
Analog Mixed Module, 12 Bit Input Current 4 Channels and Output
Current 2 Channels
D8
IC200ALG431
Analog Mixed Module, 12 Bit 0 to 10VDC Input 4 Channels and
Output 2 Channels
E2
IC200ALG432
Analog Mixed Module, 12 Bit +/-10VDC Input 4 Channels and
Output 2 Channels
E4
IC200ALG620
Analog Input Module, 16 Bit RTD, 4 Channels
D3
IC200ALG630
Analog Input Module, 16 Bit Thermocouple, 7 Channels
D4
IC200MDD840
Mixed Module, 24VDC Positive Logic Input 20 Points / Output
Relay 2.0 Amp 12 Points
C3
IC200MDD841
Mixed Module, 24VDC Positive Logic Input 20 Points / Output 12
Point / (4) High Speed Counter, PWM, or Pulse Train Configurable
Points
C4
