5-4 VersaMax® Modules, Power Supplies, and Carriers User's Manual – February 2003 GFK-1504K

IC200CHS012

Box-Style Interposing I/O Terminals

The Box-Style Interposing I/O Terminals (IC200CHS012) interface a Connector-Style I/O

Carrier to field wiring. The unit has a connector for attaching a cable from the Connector-

Style I/O Carrier and 36 box-style terminals.

IND CONT EQ FOR HAZ LOC

CLASS I DIV 2 GROUPS ABCD

Ambient 60C

MADE IN USA

IC200CHS012

I/O INTERPOSING

BOX STYLE

110.5mm

(4.35in)

97.8mm

(3.85in)

105.4mm

(4.15in)

Each terminal accommodates one solid or stranded AWG #14 (avg. 2.1mm

cross section)

to AWG #22 (avg. 0.36mm

cross section) wire, or two wires up to AWG #18 (avg.

0.86mm

cross section). A clear protective hinged door covers the wiring terminals. The

printed wiring card provided with each I/O module can be folded and inserted in this door.
