Examples
# Display the content of the IPv6 PIM routing table.
<Sysname> display pim ipv6 routing-table
Total 0 (*, G) entry; 1 (S, G) entry
(2001::2, FFE3::101)
RP: FE80::A01:100:1
Protocol: pim-sm, Flag: SPT LOC ACT
UpTime: 02:54:43
Upstream interface: Vlan-interface1
Upstream neighbor: NULL
RPF prime neighbor: NULL
Downstream interface(s) information:
Total number of downstreams: 1
1: Vlan-interface2
Protocol: pim-sm, UpTime: 02:54:43, Expires: 00:02:47
# Display the state machine information of the IPv6 PIM routing table.
<Sysname> display pim ipv6 routing-table fsm
Total 0 (*, G) entry; 1 (S, G) entry
Abbreviations for FSM states:
NI - no info, J - joined, NJ - not joined, P - pruned,
NP - not pruned, PP - prune pending, W - winner, L - loser,
F - forwarding, AP - ack pending, DR - designated router,
NDR - non-designated router, RCV - downstream receivers
(2001::2, FFE3::101)
RP: FE80::A01:100:1
Protocol: pim-sm, Flag: SPT LOC ACT
UpTime: 02:54:43
Upstream interface: Vlan-interface1
Upstream neighbor: NULL
RPF prime neighbor: NULL
Join/Prune FSM: [SPT: J] [RPT: NP]
Downstream interface(s) information:
Total number of downstreams: 1
1: Vlan-interface2
Protocol: pim-sm, UpTime: 02:54:43, Expires: 00:02:47
DR state: [DR]
Join/Prune FSM: [NI]
Assert FSM: [NI]
FSM information for non-downstream interfaces: None
Table 86 Command output
Field Descri
p
tion
Total 0 (*, G) entry; 1 (S, G) entry Number of (S, G) and (*, G) entries in the IPv6 PIM routing table.
