Lenze i510 Series Commissioning

7.4 Starng/stopping performance
7.4.1 Starng performance
The start can be oponally made with DC braking or ying restart circuit. Moreover, an auto-
mac start can be acvated aer switch-on.
Details
The start method can be selected in 0x2838:001 (P203.01). The following diagram demon-
strates the dierent start methods:
t
0 Hz
30 Hz
10 Hz
20 Hz
40 Hz
50 Hz
60 Hz
0 Hz
30 Hz
10 Hz
20 Hz
40 Hz
50 Hz
60 Hz
t
t
t
0 Hz
30 Hz
10 Hz
20 Hz
40 Hz
50 Hz
60 Hz
0 Hz
30 Hz
10 Hz
20 Hz
40 Hz
50 Hz
60 Hz
t
t
0x2838 001:
0x2838 001:
0x2838 001:
0x2DDD
DC brake
= Flying restart circuit [2]
= DC braking [1]
= Normal [0]
DC brake
DC brake
Digital input 2 [12] Run
Digital input 1 [11]
Output signals
Output frequency
Enable inverter
Input signals
Frequency setpoint selection
FunctionTrigger
①
Start method = "Normal [0]": Aer the start command, the motor is accelerated to the setpoint with the set acceleraon me.
②
Start method = "DC braking [1]": Aer the start command, the "DC braking" funcon is acve. Only aer the hold me set in 0x2B84:002
(P704.02) has elapsed, the motor is accelerated to the setpoint with the set acceleraon me.
4DC braking ^ 268
③
For demonstrang the ying restart circuit: At the me of the start command, the motor is not at standsll (for instance by loads with high
inera such as fans or ywheels).
④
Start method = "Flying restart circuit [2]": Aer the start command, the ying restart circuit is acve. The ying restart circuit serves to
restart a coasng motor on the y during operaon without speed feedback. The synchronicity between inverter and motor is coordinated
so that the transion to the rotang motor is eected without jerk at the me of connecon.
4Flying restart circuit ^ 309
Basic seng
Starng/stopping performance
Starng performance
103
