13.3.4 Network setpoint source
The following funcon is used to select the network as setpoint source.
Precondions
The setpoint change-over to the network is only eected if
•
no setpoint source with a higher priority has been selected. 4Priority of the setpoint sour-
ces ^ 367
•
no network control is acve (0x2631:037 (P400.37) = "FALSE"). If the network control is
acvated, all funcons for setpoint change-over are inacve!
Parameter Name / value range / [default seng] Info
0x2631:017
(P400.17)
Funcon list: Acvate network setpoint
(Funcon list: Setp: Network)
•
From version 02.01
•
For further possible sengs, see parameter
0x2631:001 (P400.01). ^ 351
Assignment of a trigger for the "Acvate network setpoint" funcon.
Trigger = TRUE: the network is used as setpoint source (if the trigger
assigned has the highest setpoint priority).
Trigger = FALSE: no acon / deacvate funcon again.
0 Not connected
116 Network setpoint acve (from version 02.00) TRUE if a change-over to network setpoint is requested via bit 6 of the
AC drive control word0x400B:001 (P592.01). Otherwise FALSE.
Notes:
•
Set this selecon if the network setpoint is to be acvated via bit 6 of
the AC drive control word.
•
The AC drive control word can be used with any communicaon pro-
tocol.
4AC Drive Prole ^ 193
Example for dierent applicaon cases
Example 1: The AC drive control word shall enable a change-over from the standard setpoint
source to the network setpoint (bit 6).
1.Set a standard setpoint source dierent than Network" [5]" in 0x2860:001 (P201.01).
2.Set the selecon Network setpoint acve " [116]" in 0x2631:017 (P400.17).
Example 2: Independent of the used network, a change-over from the standard setpoint
source to the network setpoint shall be possible via a digital trigger (e. g. digital input).
1.Set a standard setpoint source dierent than Network" [5]" in 0x2860:001 (P201.01).
2.Set the desired digital trigger (e. g. digital input) in 0x2631:017 (P400.17) via which the
change-over to the network setpoint is to take place.
Example 3: The setpoint is to be dened exclusively via network.
1.As standard setpoint source, set the selecon "Network [5]" in 0x2860:001 (P201.01).
Related topics
4General network sengs ^ 173
Flexible I/O conguraon
Setpoint change-over
Network setpoint source
372
