Lenze i510 Series Commissioning

Parameter Name / value range / [default seng] Info
0x230A:002
(P580.02)
CANopen stascs: PDO2 received
(CAN stascs: PDO2 received)
•
Read only
Display of the number of PDO2 telegrams received.
0x230A:003
(P580.03)
CANopen stascs: PDO3 received
(CAN stascs: PDO3 received)
•
Read only
Display of the number of PDO3 telegrams received.
0x230A:005
(P580.05)
CANopen stascs: PDO1 transmied
(CAN stascs: PDO1 transmied)
•
Read only
Display of the number of PDO1 telegrams sent.
0x230A:006
(P580.06)
CANopen stascs: PDO2 transmied
(CAN stascs: PDO2 transmied)
•
Read only
Display of the number of PDO2 telegrams sent.
0x230A:007
(P580.07)
CANopen stascs: PDO3 transmied
(CAN stascs: PDO3 transmied)
•
Read only
Display of the number of PDO3 telegrams sent.
0x230A:009
(P580.09)
CANopen stascs: SDO1 telegrams
(CAN stascs: SDO1 counter)
•
Read only
Display of the number of SDO1 telegrams.
0x230A:010
(P580.10)
CANopen stascs: SDO2 telegrams
(CAN stascs: SDO2 counter)
•
Read only
Display of the number of SDO2 telegrams.
0x230B
(P518.00)
CANopen error counter
(CAN errorcounter)
•
Read only
Display of the total number of CAN faults that have occurred.
9.4.13 LED status displays
Informaon on the CAN bus status can be obtained quickly via the "BUS RDY" and "BUS ERR"
LED displays on the front of the inverter.
The meaning can be seen from the tables below.
Inverter not acve on the CAN bus (yet)
LED "BUS RDY" LED "BUS ERR" Meaning
o
o Inverter is not acve on the CAN bus.
on
"Bus O" state.
Both LEDs are ickering alternately
Automac baud rate detecon acve.
Inverter acve on the CAN bus
The green "BUS RDY" LED indicates the CANopen state:
LED "BUS RDY" CANopen state
blinking fast (5 Hz)
Pre-Operaonal
on
Operaonal
blinking 1x, then goes o for 1 s
Stopped
The red "BUS ERR" LED indicates a CANopen error:
LED "BUS ERR" CANopen error
blinking 1x, then goes o for 1 s
Warning Limit reached
blinking 2x, then goes o for 1 s
Heartbeat Event
blinking 3x, then goes o for 1 s
Sync message error (only possible in the "Operaonal" state)
Conguring the network
CANopen
LED status displays
221
