Lenze i510 Series Commissioning

8.4.1.4 Automac motor calibraon (non-energized)
If the applicaon does not enable you to energise the system during the opmisaon, carry
out this opmisaon.
Precondions
•
All rated motor data are known and set in the inverter, either by selecng the motor from
the motor catalogue or manually.
4Motor selecon from motor catalogue ^ 144
4Manual
seng of the motor data ^ 114
•
In 0x2C00 (P300.00), the motor control type required and suitable for the motor is selec-
ted.
•
The inverter is error-free and in the "Ready to switch on" or "Switched on" device state.
•
The inverter is disabled or the motor is stopped (no start enable).
•
No other axis command is acve anymore.
Required steps
Opmisaon with engineering tool (e. g. »EASY Starter«):
1.
Go to the "Sengs" tab and navigate to the parameterisaon dialog "Advanced motor set-
ting".
2.
Click the Non-energized buon under "motor calibraon".
3.
Follow the instrucons of the engineering tool.
Opmisaon with keypad:
•
0x2822:005 (P327.05) Set = "1" to start the process.
Parameter Name / value range / [default seng] Info
0x2822:005
(P327.05)
Axis commands: Calibrate motor data (non-energized)
(Axis commands: Calibrate mot.)
0 ... [0] ... 1
1 = start automac calibraon of the motor data.
•
A default inverter characterisc is loaded.
•
the motor equivalent circuit diagram data and controller sengs are
calculated on the basis of the currently set rated motor data.
•
The motor is not energised.
Opmisaon process
As soon as the process has been started, the following steps are iniated:
1.
A default inverter characterisc is loaded.
2.
The motor equivalent circuit diagram data is calculated based on the currently set rated
motor data.
3.
The motor controller sengs are automacally calculated.
4.
The speed controller sengs are automacally calculated.
8.4.2 Inverter Characteriscs
The inverter characterisc is automacally set if one of the following opmisaons is carried
out:
4Automac motor idencaon (energized) ^ 146
4Automac motor calibraon (non-energized) ^ 147
The sengs made can be seen if required, but should not be changed. A wrong
seng may inuence the control negavely!
Parameter Name / value range / [default seng] Info
0x2947:001 ...
0x2947:017
Inverter characterisc: Value y1 ... Value y17
0.00 ... [0.00]* ... 20.00 V
* Default seng depending on the size.
The inverter characterisc (consisng of 17 values) is calculated and set
during the automac idencaon of the motor data. If only an auto-
mac calibraon of the motor data is carried out, a default inverter char-
acterisc is loaded instead.
Note!
Changing these values is not recommended by the manufacturer.
Motor control
Opmisaon of the control loops
Inverter Characteriscs
147
