Lenze i510 Series Commissioning

14.5 3-phase mains connecon 480 V
14.5.1 Rated data
The output currents apply to these operang condions:
•
At a switching frequency of 2 kHz or 4 kHz: Max. ambient temperature 45°C.
•
At a switching frequency of 8 kHz or 16 kHz: Max. ambient temperature 40 °C.
Inverter I51AE137F I51AE155F I51AE175F I51AE211F I51AE215F I51AE222F
Rated power kW 0.37 0.55 0.75 1.1 1.5 2.2
Rated power hp 0.5 0.75 1 1.5 2 3
Mains voltage range 3/PE AC 340 V ... 528 V, 45 Hz ... 65 Hz
Output voltage 3 AC 0 V … 480 V
Rated mains current
without mains choke A 1.5 2.1 2.8 3.7 4.5 6.5
with mains choke A 1.2 1.7 2.2 2.5 3.1 4.4
Apparent output power kVA 0.9 1.2 1.6 2.2 2.6 3.8
Output current
2 kHz A - 1.6 2.1 3 3.5 4.8
4 kHz A 1.1 1.6 2.1 3 3.5 4.8
8 kHz A 1.1 1.6 2.1 3 3.5 4.8
16 kHz A 0.7 1.1 1.4 2 2.3 3.2
Weight kg 0.75 0.95 1.35
Weight lb 1.7 2.1 3
Technical data
3-phase mains connecon 480 V
Rated data
429

Lenze i510 Series Specifications

General

Protection Class	IP20
Overload Capacity	150% for 60 seconds
Enclosure Rating	IP20
Dimensions	Varies by model
Weight	Varies by model
Control Type	V/f control, vector control
Communication Interfaces	CANopen, Modbus RTU, EtherCAT, PROFIBUS, PROFINET
Ambient Temperature	-10°C to +50°C
Braking Resistor	Optional
Safety	STO (Safe Torque Off)
Protection Features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Output Voltage	0 to input voltage
Input Voltage	200-240 V, 380-480 V
Voltage Range	200-240 V, 380-480 V
Frequency Range	0 to 599 Hz
