13.16 Conguraon of analog outputs
13.16.1 Analog output 1
Sengs for analog input 1.
Details
The analog output 1 is controlled with the signal selected in 0x2639:002 (P440.02).
The following sengs are possible for the analog output:
•
Denion of the signal range
①
•
Denion of the output range
②
AO1
0x2639:0010x2639 003:
0x2639 004:
X3
0x2DAA:001
V/mA
0x2639:002
0x2DAA:002
[V]
[mA]
Min
Max
Signal
Diagnosc parameters:
•
The current output voltage is displayed in 0x2DAA:001 (P112.01).
•
The actual output current is displayed in 0x2DAA:002 (P112.02).
Denion of the signal range
The signal range results from the resoluon of the selected signal mulplied by the set min
and max signal value. Signals outside the signal range are cut o. For examples, see the fol-
lowing table:
Signal
0x2639:002 (P440.02)
Resoluon Min. signal
0x2639:003 (P440.03)
Max. signal
0x2639:004 (P440.04)
Signal range
Output frequency 0.1 Hz 0 1000 0 ... 100.0 Hz
Frequency setpoint 0.1 Hz 0 1000 0 ... 100.0 Hz
Analog input 1 0.1 % 0 1000 0 ... 100.0 %
Analog input 2 0.1 % 0 1000 0 ... 100.0 %
Motor current 0.1 A 0 100 0 ... 10.0 A
Output power 0.001 kW 0 250 0 ... 0.250 kW
Torque actual value 0.1 % * 0 1000 0 ... 100.0 % *
NetWordIN3 0.1 % 200 500 20.0 ... 50.0 %
NetWordIN4 0.1 % 0 250 0 ... 25.0 %
* 100 % ≡ Motor rated torque 0x6076 (P325.00)
Detailed conguraon examples can be found in the following subchapters.
Denion of the output range
The analog output can be congured as voltage or current source. The output range selected
in 0x2639:001 (P440.01) then corresponds to the congured signal range.
Conguraon examples
Detailed conguraon examples can be found in the following subchapters:
4Example 1: Output voltage 0 ... 10 V ≡ output frequency 0 ... 100 Hz ^ 424
4Example 2: Output voltage 2 ... 10 V ≡ output frequency 30 ... 60 Hz ^ 424
Parameter Name / value range / [default seng] Info
0x2639:001
(P440.01)
Analog output 1: Output range
(Analog output 1: AO1 outp. range)
Denion of the output range.
0 Inhibited
1 0 ... 10 VDC
2 0 ... 5 VDC
3 2 ... 10 VDC
4 4 ... 20 mA
5 0 ... 20 mA
Flexible I/O conguraon
Conguraon of analog outputs
Analog output 1
422
