Lenze i510 Series Commissioning

13.7 Acvang ramp 2 manually
The "Acvate ramp 2" funcon serves to manually acvate acceleraon me 2 and decelera-
on me 2.
Parameter Name / value range / [default seng] Info
0x2631:039
(P400.39)
Funcon list: Acvate ramp 2
(Funcon list: Acv. ramp 2)
•
For further possible sengs, see parameter
0x2631:001 (P400.01). ^ 351
Assignment of a trigger for the "Acvate ramp 2" funcon.
Trigger = TRUE: acvate acceleraon me 2 and deceleraon me 2
manually.
Trigger = FALSE: no acon / deacvate funcon again.
Notes:
•
If the funcon is used and the assigned trigger = TRUE, the auto
change-over threshold 0x291B (P224.00) for ramp 2 is deacvated.
•
Acceleraon me 2 can be set in 0x2919 (P222.00).
•
Deceleraon me 2 can be set in 0x291A (P223.00).
0 Not connected
0x2917
(P220.00)
Acceleraon me 1
(Accelerat.me 1)
0.0 ... [5.0] ... 3600.0 s
Acceleraon me 1 for the operang mode "MS: Velocity mode".
•
The acceleraon me set refers to the acceleraon from standsll to
the maximum frequency set. In the case of a lower setpoint selecon,
the actual acceleraon me is reduced accordingly.
•
Seng is not eecve in the operang mode 0x6060 (P301.00) =
"CiA: Velocity mode [2]". 4Device prole CiA 402 ^ 297
0x2918
(P221.00)
Deceleraon me 1
(Decelerat.me 1)
0.0 ... [5.0] ... 3600.0 s
Deceleraon me 1 for the operang mode "MS: Velocity mode".
•
The deceleraon me set refers to the deceleraon from the maxi-
mum frequency set to standsll. In the case of a lower actual fre-
quency, the actual deceleraon me is reduced accordingly.
•
Seng is not eecve in the operang mode 0x6060 (P301.00) =
"CiA: Velocity mode [2]". 4Device prole CiA 402 ^ 297
0x2919
(P222.00)
Acceleraon me 2
(Accelerat.me 2)
0.0 ... [5.0] ... 3600.0 s
Acceleraon me 2 for the operang mode "MS: Velocity mode".
•
The acceleraon me set refers to the acceleraon from standsll to
the maximum frequency set. In the case of a lower setpoint selecon,
the actual acceleraon me is reduced accordingly.
•
The acceleraon me 2 is acve if the frequency setpoint (absolute
value) ≥ auto switching threshold 0x291B (P224.00) or the trigger
assigned to the funcon "Acvate ramp 2" in 0x2631:039 (P400.39) =
TRUE.
•
The acceleraon me 2 is also used for changing the MOP setpoint
generated by the "motor potenometer" funcon.
•
Seng is not eecve in the operang mode 0x6060 (P301.00) =
"CiA: Velocity mode [2]". 4Device prole CiA 402 ^ 297
0x291A
(P223.00)
Deceleraon me 2
(Decelerat.me 2)
0.0 ... [5.0] ... 3600.0 s
Deceleraon me 2 for the operang mode "MS: Velocity mode".
•
The deceleraon me set refers to the deceleraon from the maxi-
mum frequency set to standsll. In the case of a lower actual fre-
quency, the actual deceleraon me is reduced accordingly.
•
The deceleraon me 2 is acve if the frequency setpoint (absolute
value) ≥ auto change-over threshold 0x291B (P224.00) or the trigger
assigned to the funcon "Acvate ramp 2" in 0x2631:039 (P400.39) =
TRUE.
•
The deceleraon me 2 is also used for changing the MOP setpoint
generated by the "motor potenometer" funcon.
•
Seng is not eecve in the operang mode 0x6060 (P301.00) =
"CiA: Velocity mode [2]". 4Device prole CiA 402 ^ 297
Flexible I/O conguraon
Acvang ramp 2 manually
390
