Lenze i510 Series Commissioning

14.2 1-phase mains connecon 230/240 V
14.2.1 Rated data
The output currents apply to these operang condions:
•
At a switching frequency of 2 kHz or 4 kHz: Max. ambient temperature 45°C.
•
At a switching frequency of 8 kHz or 16 kHz: Max. ambient temperature 40 °C.
Inverter I51AE125B I51AE125D I51AE137B I51AE137D I51AE155B I51AE155D I51AE175B
Rated power kW 0.25 0.37 0.55 0.75
Rated power hp 0.33 0.5 0.75 1
Mains voltage range 1/N/PE AC 170 V ... 264 V, 45 Hz ... 65 Hz
Output voltage 3 AC 0 V … 230 V/240 V
Rated mains current
without mains choke A 4 4 5.7 5.7 7.6 7.6 10
with mains choke A 3.6 3.6 4.8 4.8 7.1 7.1 8.8
Apparent output power kVA 0.6 0.9 1.2 1.6
Output current
2 kHz A - - - - 3.2 3.2 4.2
4 kHz A 1.7 1.7 2.4 2.4 3.2 3.2 4.2
8 kHz A 1.7 1.7 2.4 2.4 3.2 3.2 4.2
16 kHz A 1.1 1.1 1.6 1.6 2.1 2.1 2.8
Weight kg 0.75 0.95
Weight lb 1.7 2.1
Inverter I51AE175D I51AE211B I51AE211D I51AE215B I51AE215D I51AE222B I51AE222D
Rated power kW 0.75 1.1 1.5 2.2
Rated power hp 1 1.5 2 3
Mains voltage range 1/N/PE AC 170 V ... 264 V, 45 Hz ... 65 Hz
Output voltage 3 AC 0 V … 230 V/240 V
Rated mains current
without mains choke A 10 14.3 14.3 16.7 16.7 22.5 22.5
with mains choke A 8.8 11.9 11.9 13.9 13.9 16.9 16.9
Apparent output power kVA 1.6 2.2 2.6 3.6
Output current
2 kHz A 4.2 6 6 7 7 9.6 9.6
4 kHz A 4.2 6 6 7 7 9.6 9.6
8 kHz A 4.2 6 6 7 7 9.6 9.6
16 kHz A 2.8 4 4 4.7 4.7 6.4 6.4
Weight kg 0.95 1.35
Weight lb 2.1 3
Technical data
1-phase mains connecon 230/240 V
Rated data
427
