Lenze i510 Series Commissioning

11.3 Wireless LAN (WLAN)
The pluggable WLAN module enables
•
an easy access to inverters that are installed in dicult access areas,
•
an easy parameter seng without cable and instead of the keypad,
•
a comfortable monitoring and adaptaon of the machine.
The inverter can be accessed via WLAN with the following devices:
•
Engineering PC (with WLAN funconality) and the »EASY Starter« engineering tool.
•
Android smartphone with Lenze Smart Keypad App.
The Lenze Smart Keypad App is recommended for the adaptaon of simple applicaons. The
Lenze Smart Keypad App can be found in the Google Play Store.
11.3.1 WLAN LED status displays
Informaon on the WLAN module status can be obtained quickly via the LED displays "Power",
"TX/RX" and "WLAN" on the front of the WLAN module.
The meaning can be seen from the table below.
LED "Power" (green) LED "TX/RX" (yellow) LED "WLAN" (green) Status/meaning
o o o No supply voltage.
on on on
Self-test (duraon approx. 1 s)
o o Ready for operaon — no acve WLAN connecon.
Flashing on
Communicaon acve.
o
blinking
Client mode — waing for connecon.
blinking
o o Trouble
Aer being plugged in, the WLAN module needs approx. 20 seconds unl it is
ready for operaon.
Addional funcons
Wireless LAN (WLAN)
WLAN LED status displays
257
