Lenze i510 Series Commissioning

Parameter Name / value range / [default seng] Info
0x2DA5:016
(P111.16)
Diagnoscs of analog input 2: Status
(AI2 diagnoscs: AI2 status)
•
Read only
•
From version 04.00
Bit-coded display of the status of analog input 2 (X3/AI2).
Bit 0 Mode 0: 0 ... 10 VDC acve
Bit 1 Mode 1: 0 ... 5 VDC acve
Bit 2 Mode 2: 2 ... 10 VDC acve
Bit 3 Mode 3: -10 ... 10 VDC acve
Bit 4 Mode 4: 4 ... 20 mA acve
Bit 5 Mode 5: 0 ... 20 mA acve
Bit 6 24 V supply OK
Bit 7 Calibraon successful
Bit 8 Monitoring threshold exceeded/not reached
Bit 9 Input current too low
Bit 10 Input voltage too low
Bit 11 Input voltage too high
0x2DAA:001
(P112.01)
Diagnoscs of analog output 1: Voltage
(AO1 diagnoscs: AO1 Voltage)
•
Read only: x.xx V
Display of the current output voltage at X3/AO1.
0x2DAA:002
(P112.02)
Diagnoscs of analog output 1: Current
(AO1 diagnoscs: AO1 Current)
•
Read only: x.xx mA
Display of the present output current at X3/AO1.
Related topics
4Conguraon of analog inputs ^ 409
4Conguraon of analog outputs ^ 422
6.2.6 Wireless-LAN diagnoscs
The following parameters serve to diagnose the WLAN module and the WLAN communica-
on.
Precondions
WLAN module has been plugged onto the interface X16 on the front of the inverter.
Parameter Name / value range / [default seng] Info
0x2442:001 Acve WLAN sengs: Acve IP address
•
Read only
•
From version 02.00
Display of the acve IP address.
•
If DHCP is acvated, the acve IP address usually derives from the
congured stac IP address of the device.
0x2442:002 Acve WLAN sengs: Acve netmask
•
Read only
•
From version 02.00
Display of the acve netmask.
0x2442:003 Acve WLAN sengs: Acve gateway
•
Read only
•
From version 02.00
Display of the acve gateway IP address.
0x2442:004 Acve WLAN sengs: Acve module mode
•
Read only
•
From version 02.00
Display of the acve data source for the WLAN sengs.
•
This parameter indicates whether the sengs used come from the
inverter or from the WLAN module.
0 Inverter The WLAN sengs saved in the inverter are used.
1 Standalone The WLAN sengs saved in the WLAN module are used.
0x2442:005 Acve WLAN sengs: MAC address
•
Read only
•
From version 02.00
Display of the MAC address of the WLAN module.
0x2448:001 WLAN status: Connecon me
•
Read only
•
From version 02.00
Display of the connecon me in [s] since the current connecon was
established.
0x2448:002 WLAN status: Number of connecons
•
Read only
•
From version 02.00
In access point mode: Display of the number of currently connected cli-
ents.
In client mode: 0 ≡ not connected; 1 ≡ connected with external WLAN
network.
Diagnoscs and fault eliminaon
Diagnoscs parameter
Diagnoscs of the inputs and outputs
83
