5-3
Flow of Test Run
Perform a test run of the inverter according to the following flow.
Item Description Reference
Installation Install the inverter according to the installation
conditions.
2-1-1 Inverter Installation on
page 2-
2
Wiring and connections Connect the inverter to the power supply and pe-
ripheral equipment.
2-3 Wiring on page 2-10
Configuration of Ether-
CAT Slave/Units
Sysmac Studio is used to create new projects and
slave/units configuration off-line or on-line.
Sysmac Studio V
ersion 1
Operation Manual (Cat. No.
W504)
Node Address Setting Set the node address.
3-1-1 Node Address Setting on
page 3-2
Power-on Check the points mentioned in the next page be-
fore turning the power supply ON.
5-4 Operation Items for Test Run
on page 5-7
Display status checks Check that no error is occurring on the inverter. Section 9 Troubleshooting on
page 9-1
Parameter Initialization Initialize inverter parameters. 6-1 Data Initialization on page
6-3
Parameter setting Set the parameters required for the test run. 6-3 Motor Parameter Settings on
page 6-17
6-4 RUN command on page
6-22
No-load run Run the motor in a no-load state. Section 6 Basic Settings on
page 6-1
5 Operation and Test Run
5-5
M1 Series EtherCAT Type User’s Manual (I670)
5-3 Flow of Test Run
5
To Next Page
