H Group Parameter List (High Level Functions)
Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
3008 04 H03 Data Initialization
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0: Disable
1: Initialize all parameters
2: Initialize motor 1 parameters
3: Initialize motor 2 parameters
4: Restore user defined data
5: Initialize all parameters (except I/O
and communications)
6: Reserved
7: Clear alarm history
8: Clear selection of favorite function
code
0 --- --- Possible
05 H04 Retry Count at
Trip
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0: Disable
1 to 20: Number of retries
0
√
--- Possible
06 H05 Retry Standby
Time at T
rip
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0.5 to 20.0
5
√
s Possible
07 H06 Cooling Fan
Function Selec-
tion
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0: Always Fan ON
1: ON/OFF control effective
0
√
---
Possible
08 H07 Acceleration/
Deceleration Pat-
tern Selection
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0: Disable (Linear acceleration/decel-
eration)
1: S-curve acceleration/deceleration
(Weak)
2: S-curve acceleration/deceleration
(Arbitrary: According to H57 to H60)
3: Curve acceleration/deceleration
0
√
---
Possible
09 H08 Reverse Rotation
Prevention Func-
tion
V/f DTV
PG V/f PG DTV
SLV PGV
PM SLV PM PGV
0: Disable
1: Reverse rotation inhibited
2: Forward rotation inhibited
0 --- --- Possible
Appendices
A-133
M1 Series EtherCAT Type User’s Manual (I670)
A-4 Lists of Manufacturer Specific Objects 2
(Inverter Parameters)
A
A-4-9 H Group Parameter List (High Level Functions)
