Side-by-side installation
Side-by-side inverter installation (minimum clearance between inverters of 4 mm) is supported.
This realizes the downsizing of control panels and the integration of devices into control panels,
and helps reduce engineering costs.
Depending on the model, the reduction of the carrier frequency and the derating of the rated cur-
rent are required. Refer to 2-1-2 Installation Environment on page 2-2 for details.
Usability
Same look and feel operability
In the design of Sysmac Studio, attention has been paid to operability so that it has the same look
and feel as in OMRON's drive products. This minimizes the need to familiarize yourself with new
operations generally required with software tools, and helps improve the efficiency of development
when designing and starting up new systems.
1-1-2
Classes of 3G3M1 Series Inverter
There are three voltage classes for 3G3M1 Series Inverters: 200-V class supporting single-phase 200
V
AC and three-phase 200 V
AC, and 400-V class supporting three-phase 400 VAC.
The maximum applicable motor capacity for this inverter is 0.1 to 22 kW for the heavy load mode and
0.2 to 30 kW for the light load mode.
All models comply as standard with the EC Directives and UL/cUL Standards.
Rated voltage Enclosure rating
Maximum applicable motor ca-
pacity
Model
HHD: Heavy
load
HND: Light
load
Three-phase 200 VAC IP20 0.1 kW 0.2 kW 3G3M1-A2001-ECT
0.2 kW 0.4 kW 3G3M1-A2002-ECT
0.4 kW 0.75 kW 3G3M1-A2004-ECT
0.75 kW 1.1 kW 3G3M1-A2007-ECT
1.5 kW 2.2 kW 3G3M1-A2015-ECT
2.2 kW 3.0 kW 3G3M1-A2022-ECT
3.7 kW 5.5 kW 3G3M1-A2037-ECT
5.5 kW 7.5 kW 3G3M1-A2055-ECT
7.5 kW 11 kW 3G3M1-A2075-ECT
11 kW 15 kW 3G3M1-A2110-ECT
15 kW 18.5 kW 3G3M1-A2150-ECT
18.5 kW 22 kW 3G3M1-A2185-ECT
1 Overview
1-3
M1 Series EtherCAT Type User’s Manual (I670)
1-1 Overview of Functions
1
1-1-2 Classes of 3G3M1 Series Inverter
