6-5
Frequency Reference
6-5-1
Frequency Reference Selection
Select the input method for the frequency reference.
Parameter
No.
Function name Data
Default da-
ta
Unit
3004Hex-0
2Hex/
3006Hex-1
FHex
1st Frequency Reference
Selection/2nd Frequency
Reference Selection
*1
1: Analog Valtage Input (Input Termi-
nal[AI1])
7: UP/DOWN control
10: Pattern operation
12: Pulse train input
13: Calculation result
15: EtherCAT
15 -
3002Hex-0
7Hex
Operation command
Bit1: REV
Bit0: FWD
0 -
Related function Input T
erminal [DI1] to [DI7] Function Selection (3005Hex-02Hex to
3005Hex-06Hex, 3005Hex-63Hex, 3005Hex-64Hex)
*1. To enable switching to the 1st and 2nd control, allocate “12: SET (2nd control)” to either of input terminal
[DI1] to [DI7].
The frequency reference method for data selected at 1st Frequency Reference Selection
(3004Hex-02Hex) and 2nd Frequency Reference Selection (3006Hex-1FHex) is as follows.
Data Frequency reference method
1 Sets the frequency reference via the analog voltage input (input terminal [AI1]).
7 Sets the frequency reference via the UP and DOWN terminals.
10 Sets the frequency reference via Pattern Operation Function Selection.
12 Sets the frequency reference via pulse train input.
13
The result of calculation of the frequency calculation function is set as the frequen-
cy reference.
14 Sets the frequency reference via EtherCAT communication.
The forced terminal block function are given priority over the frequency reference selected at Fre-
quency Reference Selection (3004Hex-02Hex/3006Hex-1FHex). For details, refer to 8-6-3 STO
Function by Safety Input Signal on page 8-62
.
Command Using Analog Voltage Input (Frequency Reference Se-
lection (3004Hex-02Hex/3006Hex-1FHex) = “1”)
Analog input can adjust the input signal by gain and bias. (Refer to 8-3-2 Analog Input Adjustment
Function on page
8-34.)
Behavior when the analog signal is disconnected can be set at analog reference loss detection.
Analog Reference Loss Detection
When the analog frequency reference falls to 10% or lower of the frequency reference for 400 ms,
the wiring of the analog frequency reference is judged to have become disconnected, operation is
6 Basic Settings
6-24
M1 Series EtherCAT Type User’s Manual (I670)
