excessive positional deviation alarm (d0) can be reset when the alarm stops and inverter output turns
OFF.
Positional deviation is closely related to positioning frequency and position command gain. When a
certain frequency reference is output at a certain position reference gain, a constant positional devia-
tion is always required. Due to this fact, positional deviation can be improved by either increasing the
detection level of excessive positioning deviation (3037Hex-18Hex, 3037Hex-19Hex) or by increasing
the position control gain (3037Hex-04Hex and 3037Hex-05Hex) when the excessive positional devia-
tion alarm (d0) occurs.
Parameter No. Function name Data
Default
data
Unit
3037Hex-18He
x
Detection Level of Excessive Po-
sitioning Deviation (MSB)
0: Disable (MSB: 0, LSB: 0)
1 to 268435455 (MSB: 0 to 4,095,
LSB: 0 to 65,535)
0 -
3037Hex-19He
x
Detection Level of Excessive Po-
sitioning Deviation (LSB)
0 -
7-7-18
Touch Probe (Latch) Function
This is a function that latches the feedback position when the external latch input signal or the encoder
Z-phase is started.
This function is disabled if neither of “187: EXT1 (External latch input 1)” and “188: EXT2 (External
latch input 2)” is allocated to Input Terminal [DI1] Function Selection (3005Hex-02Hex) and Input T
er-
minal [DI2] Function Selection (3005Hex-03Hex), and if the selection trigger is not encoder Z-phase.
This function is also disabled when bit 0 (Latch function 1) and bit 8 (Latch function 2) of Touch Probe
Function (3052Hex-26Hex) are 0.
Parameter No. Function name Data Default data Unit
3052Hex-24Hex
Touch Probe 1 Source 1: External Latch Input 1 (EXT1)
2: External Latch Input 2 (EXT2)
6: Encoder Phase Z
1 -
3052Hex-25Hex
Touch Probe 2 Source 1: External Latch Input 1 (EXT1)
2: External Latch Input 2 (EXT2)
6: Encoder Phase Z
1 -
3052Hex-26Hex Touch Probe Function 0000 to FFFF hex 0 -
3017Hex-31Hex
Touch Probe 1 Positive
Edge (MSB)
-4096 to 4095
0 -
3017Hex-32Hex
Touch Probe 1 Positive
Edge (LSB)
0 to 65535
0 -
3017Hex-33Hex
Touch Probe 2 Positive
Edge (MSB)
-4096 to 4095
0 -
3017Hex-34Hex
Touch Probe 2 Positive
Edge (LSB)
0 to 65535
0 -
3017Hex-35Hex Touch Probe Status 0000 to FFFF hex 0 -
3005Hex-02Hex,
3005Hex-03Hex
Input Terminal [DI1]
Function Selection, In-
put T
erminal [DI2]
Function Selection
187: EXT1 (External latch input 1)
*1
188: EXT2 (External latch input 2)
*1
- -
*1. External latch cannot be allocated to other than multifunction input DI1 and DI2.
7 Vector Control and Applied Functions
7-62
M1 Series EtherCAT Type User’s Manual (I670)
To Next Page
