1-2
Appearance and Part Names
The following shows the front view when the product is unpacked.
(An example of 3G3M1-AB001/AB002/AB004/AB007/A2001/A2002/A2004/A2007-ECT)
Open the terminal block cover to wire the main circuit terminal block and the control circuit terminal
block.
Control circuit terminal block A
Digital input sink/
source selector switch (SW1)
Control circuit terminal block B
Safety input terminal block
Auxiliary power supply input terminal
Safety function selector switch (SW
9)
Control circuit terminal block C
USB connector
(Micro-B)
Relay output terminal block
Main circuit terminal block
(Factory default)
SINK
SOURCE
OFFON
1 Overview
1-6
M1 Series EtherCAT Type User’s Manual (I670)
