Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
61 E196 Overtorque/
Undertorque De-
tection Level Re-
verse Power
Running
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 300
100 --- % Possible
62 E197 Overtorque/
Undertorque De-
tection Level For-
ward Regenera-
tion
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 300
100 --- % Possible
63 E198 Overtorque/
Undertorque De-
tection Condition
Selection
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: Output during acceleration/decel-
eration and constant-speed opera-
tion
1: Output only during constant-speed
operation
0 --- --- Possible
64 E199 0Hz Detection
Output Detection
Level (ZS)
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 100.00
0 --- Hz Possible
*1. For SDO communications and PDO communications, it is 7FFF hex.
A-4-7
C Group Parameter List (Frequency Reference and Analog Input
Functions)
Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
3006 02 C01 Jump Frequency
1
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.0 to 590.0
0.0
√
Hz Possible
03 C02 Jump Frequency
2
04 C03 Jump Frequency
3
05 C04 Jump Frequency
Skip Width
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.0 to 30.0
3.0
√
Hz Possible
Appendices
A-125
M1 Series EtherCAT Type User’s Manual (I670)
A-4 Lists of Manufacturer Specific Objects 2
(Inverter Parameters)
A
A-4-7 C Group Parameter List (Frequency Reference and Analog Input Functions)
