Error Descriptions
This section describes errors.
Error Table
The items that are used to describe individual errors (events) are described in the following copy of an
error table.
Event name Gives the name of the error (event). Event code Gives the code of the error
(event).
Description Gives a short description of the error (event).
Source Gives the source of the error
(event).
Source details Gives details
on the source
of the error
.
Detection tim-
ing
T
ells when the
error is detect-
ed.
Error attrib-
utes
Level Tells the influ-
ence on con-
trol.
*1
Recovery Gives the re-
covery meth-
od.
*2
Log category Tells which log
the error is
saved in.
Effects User program Tells what will
happen to exe-
cution of the
user pro-
gram.*
*3
Operation Provides special information on the operation that
results from the error (event).
Indicators EtherCAT NET RUN EtherCAT NET ERR EtherCAT LINK/ACT
Gives the status of the built-in EtherNet/IP port and built-in EtherCAT port indicators. Indicator status is
given only for errors in the EtherCAT Master Function Module and the EtherNet/IP Function Module.
System-de-
fined varia-
bles
V
ariable Data type Name
Lists the variable names, data types, and meanings for system-defined variables that provide direct error
notification, that are directly affected by the error
, or that contain settings that cause the error.
Cause and
correction
Assumed cause Correction Prevention
Lists the possible causes, corrections, and preventive measures for the error (event).
Attached in-
formation
Provides the additional information that is displayed by the Sysmac Studio or an NS-series PT.
Precautions/
Remarks
Provides precautions, restrictions, and supplemental information.
*1. One of the following:
Minor fault: Minor fault level
Observation
Information
*2. One of the following:
Automatic recovery: Normal status is restored automatically when the cause of the error is removed.
Error reset: Normal status is restored when the error is reset after necessary measures are taken.
Cycle the power supply: Normal status is restored when the power supply is turned OFF and then back ON after nec-
essary measures are taken.
Replace the inverter: Normal status is restored when the inverter is replaced with a new one.
*3. "Continues." indicates that execution of the user program will continue.
Appendices
A-219
M1 Series EtherCAT Type User’s Manual (I670)
A-5 Sysmac Error Status Codes
A
A-5-2 Error Descriptions
