A-3

Object List

Index

(hex)

Subin-

dex

(hex)

Object name Setting range Unit Default setting Size Access

PDO

map

1000 00 Device Type --- --- 00090192 hex 4 bytes

(U32)

RO Not pos-

sible

1001 00 Error Register 00 to FF hex --- 00 hex 1 byte

(U8)

RO Not pos-

sible

1008 00 Manufacturer Device

Name

--- --- 00 hex 20 bytes

(VS)

RO Not pos-

sible

1009 00 Manufacturer Hard-

ware Version

--- --- 00 hex

20 bytes

(VS)

RO Not pos-

sible

100A 00 Manufacturer Soft-

ware Version

--- --- 00 hex

20 bytes

(VS)

RO Not pos-

sible

1010 --- Store Parameters

00 Number of Entries --- --- 01 hex 1 byte

(U8)

RO Not pos-

sible

01 Store Parameters 00000000 to

FFFFFFFF hex

--- 00000001 hex 4 bytes

(U32)

RW Not pos-

sible

1011 --- Restore Default Parameters

00 Number of Entries --- --- 01 hex 1 byte

(U8)

RO Not pos-

sible

01 Restore Default Pa-

rameters

00000000 to

FFFFFFFF hex

--- 00000001 hex 4 bytes

(U32)

RW Not pos-

sible

1018 --- Identity Object

00 Number of Entries --- --- 04 hex 1 byte

(U8)

RO Not pos-

sible

01 Vendor ID --- --- 00000083 hex 4 bytes

(U32)

RO Not pos-

sible

02 Product Code 00000000 to

FFFFFFFF hex

--- 00000000 hex 4 bytes

(U32)

RO Not pos-

sible

03 Revision Number 00000000 to

FFFFFFFF hex

--- 00000000 hex 4 bytes

(U32)

RO Not pos-

sible

04 Serial Number 00000000 to

FFFFFFFF hex

--- 00000000 hex 4 bytes

(U32)

RO Not pos-

sible

10E0 --- Device Identification Reload Object

00 Number of Entries --- --- 03 hex 1 byte

(U8)

RO Not pos-

sible

01 Configured Station

Alias Register V

alue

0000 to FFFF hex

--- 0000 hex 2 bytes

(U16)

RW Not pos-

sible

03 Reload ID-Selector

Value

0000 to FFFF hex

--- 0000 hex 2 bytes

(U16)

RW Not pos-

sible

10F3 --- Diagnosis History

00 Number of Entries --- --- 0D hex 1 byte

(U8)

RO Not pos-

sible

01 Maximum Messages 00 to 08 hex --- 00 hex 1 byte

(U8)

RO Not pos-

sible

02 Newest Message 00 to 0D hex --- 00 hex 1 byte

(U8)

RO Not pos-

sible

03 Newest Acknowl-

edged Message

00 to FF hex --- 00 hex 1 byte

(U8)

RW Not pos-

sible

04 New Messages

vailable

ALSE or TRUE --- FALSE 1 bit

(BOOL)

RO Possible

(TxPDO)

Appendices

A-39

M1 Series EtherCAT Type User’s Manual (I670)
