7-10
Peripheral speed constant control
In winding systems such as wire drawing machines and spinning machines, the outer diameter of the
wind-up roll increases due to the amount of material being wound onto the roll and the actual wind-up
speed increases when winding is continued at a constant shaft speed. To maintain the wind-up speed
at the outer periphery at a constant speed, a speed sensor is used to detect the wind-up speed, and
the speed of the motor shaft is controlled so that the wind-up speed is kept constant.
7-10-1
Line Speed Control Settings
Set enable/disable status for line speed control.
Parameter
No.
Function name Data Default data Unit
3014Hex-2AH
ex
Special Control Selec-
tion
1: Line speed control with speed sen-
sor
0 -
3014Hex-10H
ex
Input Terminal [PIA][PIB]
Encoder Pulse Resolu-
tion
20 to 60000 1024 Pulse
3014Hex-11H
ex
Input Terminal [PIA][PIB]
Pulse Scaling Factor
Denominator
1 to 32767 1 -
3014Hex-12H
ex
Input Terminal [PIA][PIB]
Pulse Scaling Factor
Numerator
1 to 32767 1 -
3005Hex-02H
ex to
3005Hex-06H
ex,
3005Hex-63H
ex,
3005Hex-64H
ex
Input Terminal [DI1] to
[DI7] Function Selection
70: Line speed control cancellation
71: Line speed control frequency
memory
- -
Machine Configuration and Settings
The following parameters must be set when the mechanical system of a winder is configured as
shown in the figure below.
7 Vector Control and Applied Functions
7-78
M1 Series EtherCAT Type User’s Manual (I670)
