4-17

4 Controller Setup

NJ-series CPU Unit Software User’s Manual (W501)

4-5 Initial Settings for the EtherCAT Master Function Module

4-5 Initial Settings for the EtherCAT

Master Function Module

This section describes the initial settings that are required for the EtherCAT Master Function Module.

The initial settings for the EtherCAT Master Function Module are listed below.

• Device names

• Total Cable Length

• Fail-soft Operation Settings

• Wait Time for Slave Startup

• PDO Communications Timeout Detection Count

• Revision Check Method

• Serial Number Check Method

Double-click EtherCAT under Configurations and Setup and then select the master on the Sysmac

Studio. The Initial Setting Tab Page for the EtherCAT Master Function Module is displayed.

Refer to the NJ-series CPU Unit Built-in EtherCAT Port User’s Manual (Cat. No. W505) for details.
