Appendices
A-124
NJ-series CPU Unit Software User’s Manual (W501)
A-12 Version Information
This section describes the relationship between the unit versions of CPU Units and the Sysmac Studio
versions, and the functions that are supported for each unit version.
This section describes how the unit versions of CPU Units correspond to Sysmac Studio versions. Nor-
mally use the corresponding versions.
The following table gives the relationship between unit versions of CPU Units and the corresponding
Sysmac Studio versions.
*1 There is no NJ301- CPU Unit with unit version 1.00. Therefore, you cannot use an NJ301-
CPU Unit with Sysmac Studio version 1.01 or lower.
The specifications when you do not use the Sysmac Studio version that corresponds to the unit version
of the CPU Unit are given in this section.
Using an Lower Sysmac Studio Version
If you use a lower version of the Sysmac Studio, you can use only the functions of the unit version of
the CPU Unit that corresponds to the Sysmac Studio version.
Example: Unit version of CPU Unit: 1.04
Sysmac Studio version: 1.04
Unit version 1.03 of the CPU Unit corresponds to Sysmac Studio version 1.04. There-
fore, you can use only the functions that are supported by unit version 1.03 of the CPU
Unit. You cannot use functionality that was added for unit version 1.04 or later of the
CPU Unit.
A-12-1 Relationship between Unit Versions of CPU Units and Sysmac
Studio Versions
Unit Versions and Corresponding Sysmac Studio Versions
Unit version of CPU Unit Corresponding version of Sysmac Studio
Ver.1.08 Ver.1.09
Ver.1.07 Ver.1.08
Ver.1.06 Ver.1.07
Ver.1.05 Ver.1.06
Ver.1.04 Ver.1.05
Ver.1.03 Ver.1.04
Ver.1.02 Ver.1.03
Ver.1.01 Ver.1.02
Ver.1.00
*1
Ver.1.01
Ver.1.00
Specifications When Not Using the Sysmac Studio Version That
Corresponds to the Unit Version of the CPU Unit
