Appendices
NJ-series CPU Unit Software User’s Manual (W501)
A-3 System-defined Variables
App
A-3-6 EtherNet/IP Function Module, Category Name: _EIP
 Functional Classification: EtherNet/IP Communications Errors
A-3-6 EtherNet/IP Function Module, Category Name: _EIP
Variable name Meaning Function Data type
Range of
values
Reference
_EIP_ErrSta Built-in
EtherNet/IP Error
This is the error status variable for the built-in
EtherNet/IP port.
It represents the following error flags.
• _EIP_PortErr (Communications Port Error)
• _EIP_CipErr (CIP Communications Error)
• _EIP_TcpAppErr (TCP Application Commu-
nications Error)
Note Refer to information on the meanings of
the error status bits at the end of this
appendix for details.
WORD 16#0000 to
16#00F0
page A-73
_EIP_PortErr Communications
Port Error
This is the error status variable for the com-
munications port.
It represents the following error flags.
• _EIP_MacAdrErr (MAC Address Error)
• _EIP_LanHwErr (Communications Control-
ler Error)
• _EIP_EtnCfgErr (Basic Ethernet Setting
Error)
• _EIP_IPAdrCfgErr (TCP/IP Basic Setting
Error)
• _EIP_IPAdrDupErr (IP Address Duplication
Error)
• _EIP_BootpErr (BOOTP Server Error)
• _EIP_IPRTblErr (TCP/IP Advanced Setting
Error)
Note If a Link OFF or Built-in EtherNet/IP
Processing Error occurs, it is recorded
in the event log and then the corre-
sponding bit turns ON. Refer to infor-
mation on the meanings of the error
status bits at the end of this appendix
for details.
WORD 16#0000 to
16#00F0
page A-73
