Related Manuals
NJ-series CPU Unit Software User’s Manual (W501)
Related Manuals
The followings are the manuals related to this manual. Use these manuals for reference.
Manual name Cat. No. Model numbers Application Description
NJ-series CPU Unit
Hardware User’s Manual
W500 NJ501-
NJ301-
Learning the basic specifi-
cations of the NJ-series
CPU Units, including intro-
ductory information, design-
ing, installation, and
maintenance. Mainly hard-
ware information is pro-
vided.
An introduction to the entire NJ-series system is
provided along with the following information on
the CPU Unit.
• Features and system configuration
• Introduction
• Part names and functions
• General specifications
• Installation and wiring
• Maintenance and inspection
Use this manual together with the NJ-series CPU
Unit Software User’s Manual (Cat. No. W501).
NJ-series CPU Unit Soft-
ware User’s Manual
W501 NJ501-
NJ301-
Learning how to program
and set up an NJ-series
CPU Unit. Mainly software
information is provided.
The following information is provided on a Control-
ler built with an NJ501 CPU Unit.
• CPU Unit operation
• CPU Unit features
• Initial settings
• Programming based on IEC 61131-3 language
specifications
Use this manual together with the NJ-series CPU
Unit Hardware User’s Manual (Cat. No. W500).
NJ-series Instructions
Reference Manual
W502 NJ501-
NJ301-
Learning detailed specifica-
tions on the basic instruc-
tions of an NJ-series CPU
Unit.
The instructions in the instruction set (IEC 61131-3
specifications) are described. When program-
ming, use this manual together with the NJ-series
CPU Unit Hardware User’s Manual (Cat. No.
W500) and NJ-series CPU Unit Software User’s
Manual (Cat. No. W501).
NJ-series CPU Unit
Motion Control User’s
Manual
W507 NJ501-
NJ301-
Learning about motion con-
trol settings and program-
ming concepts.
The settings and operation of the CPU Unit and
programming concepts for motion control are
described. Use this manual together with the NJ-
series CPU Unit Hardware User’s Manual (Cat. No.
W500) and NJ-series CPU Unit Software User’s
Manual (Cat. No. W501).
NJ-series Motion Control
Instructions Reference
Manual
W508 NJ501-
NJ301-
Learning about the specifi-
cations of the motion control
instructions that are pro-
vided by OMRON.
The motion control instructions are described.
When programming, use this manual together with
the NJ-series CPU Unit Hardware User’s Manual
(Cat. No. W500), NJ-series CPU Unit Software
User’s Manual (Cat. No. W501) and NJ-series
CPU Unit Motion Control User’s Manual (Cat. No.
W507).
NJ-series CPU Unit Built-
in EtherCA
T® Port User’s
Manual
W505 NJ501-
NJ301-
Using the built-in EtherCAT
port on an NJ-series CPU
Unit.
Information on the built-in EtherCAT port is pro-
vided. This manual provides an introduction and
provides information on the configuration, features,
and setup.
Use this manual together with the NJ-series CPU
Unit Hardware User’s Manual (Cat. No. W500) and
NJ-series CPU Unit Software User’s Manual (Cat.
No. W501).
NJ-series CPU Unit Built-
in EtherNet/IP
TM
Port
User’s Manual
W506 NJ501-
NJ301-
Using the built-in Ether-
Net/IP port on an NJ-series
CPU Unit.
Information on the built-in EtherNet/IP port is pro-
vided. Information is provided on the basic setup,
tag data links, and other features.
Use this manual together with the NJ-series CPU
Unit Hardware User’s Manual (Cat. No. W500) and
NJ-series CPU Unit Software User’s Manual (Cat.
No. W501).
NJ-series Database Con-
nection CPU Units User’s
Manual
W527 NJ501-120 Using the database connec-
tion service with NJ-series
Controllers
Describes the database connection service.
