Omron NJ Series User Manual

9-49
9 Backup Functions
NJ-series CPU Unit Software User’s Manual (W501)
9-11 Backup-related Files
9
9-11-5 Specifications of a Controller Verification Results File
This section describes the file name, creation timing, created directory, and verification results confir-
mation method for a Controller verification results file.
Note However, if the SD Memory Card is write-protected, the verification results files will not be created.
The verification results files contain the results of comparing the Controller data and the data in a
backup file on the SD Memory Card in the CPU Unit for each data group. You can check the verification
results in the portion that gives the verification results for each data group. “Result=Matched” indicates
a data group for which no differences were found. “Result=Not matched” indicates a data group for
which differences were found. In the file shown below, the user program and configuration data
matched, and the Units and slave parameters did not match.
Note The verification results are given only for the data groups that were compared.
This section describes the file name, creation timing, created directory, and verification results confir-
mation method for an EtherCAT verification results file.
9-11-5 Specifications of a Controller Verification Results File
File name
File File name
Controller Verification Results File VerifyResult.log
File Creation Timing and Created Directories
Function Procedure Creation timing Created directory
SD Memory
Card backups
SD Memory Card Dialog Box
in Sysmac Studio
When verification is executed Same directory as backup file
System-defined variables When verification is executed Same directory as backup file
CPU Unit front-panel DIP
switch
When verification is executed Same directory as backup file
How to Check the Verification Results
File contents Description
[UserProgram]
; --- User Program and Configuration. ---
Result=Matched
[UnitConfig]
; --- Unit/Slave Parameters. ---
Result=Not matched
User program and settings
Matched: No differences were found, Not matched: Differ-
ences were found.
Units and slaves settings
Matched: No differences were found, Not matched: Differ-
ences were found.
9-11-6 Specifications of an EtherCAT Verification Results File
File Name
File File name
EtherCAT Verification Results File VerifyResult_ECAT.log
