3-5. NETWORK SETTINGS Menu
N01: IP ADDR SET
Menu Image Item Settings Description
<IP ADDR SET> N01 TOP
HOST IP ADDRESS
0. 0. 0. 0
SUB NET MASK
0. 0. 0. 0
DEFUALT GATEWAY
0. 0. 0. 0
SET
HOST IP AD-
DRESS
0.0.0.0 to
255.255.255.255
Displays the IP address.
SUB NET
MASK
0.0.0.0 to
255.255.255.255
Displays the subnet mask.
DEFAULT
GATEWAY
0.0.0.0 to
255.255.255.255
Displays the default gateway.
SET － Determines changes in the page.
N02: LAN SETTING
Menu Image Item Settings Description
<LAN SETTING> N02 TOP
AUTO NEGOTIATION : ON
AUTO MDIX : ON
CONNECT CONFIGURATION
CONNECT SPEED : 100M
DUPLEX MODE : FULL
MDI/MDIX SELECT : MDI
LINK CONDITION :(DOWN)
SET
AUTO NEGOTIATION ON, OFF Selects whether to auto-
matically set the con-
nection speed and com-
munication system ac-
cording to the device
connected.
AUTO MDIX ON, OFF Sets the communication
line.
CONNECT
CONFIGURATION
CONNECTION
SPEED
10M,
100M
Selects the connection
speed.
10M: 10BASE-TX
100M: 100BASE-TX
Available only when
OFF is selected in AU-
TO NEGOTIATION.
DUPLEX
MODE
HALF,
FULL
Selects the communica-
tion system.
HALF: Half-duplex
communication.
FULL: Full-duplex
communication.
Available only when
OFF is selected in AU-
TO NEGOTIATION.
MDI/MDIX SE-
LECT
MDI,
MDIX
Selects the communica-
tion line.
LINK CONDITION (DOWN),
(UP)
Displays connection sta-
tus. (Display only)
(DOWN): Connection
failure
(UP): Connection suc-
cessful
SET － Determines changes in
the page.
HDCU2500
3-27
