Sony HDCU2500 Maintenance Manual

AVP board diagnostics
Menu Image Item Description
*AVP Diag* 10/17
Front Power:OK
PLD Version:1.00 Done
ADO Power :OK
Front Power Status of power supply to the AVP board
PLD Version AVP board PLD version
ADO Power Status of power supply to the ADO board
DTX board diagnostics
Menu Image Item Description
*DTX Diag* 11/17
Return Delay :F/S
Active Ret CH :2CH
Front Power:OK
PLD Version:1.00 Done
Rear:SDI Power:OK
Return Delay Return delay setting status
Active Ret CH The selected RET channel
Front Power Status of power supply to the DTX board
PLD Version DTX board PLD version
Rear Name of the board installed in the rear slot
Power Status of power supply to the board installed in the slot
3-2-7. Status of the Board Inserted in Slot
Note
The items displayed differ depending on board connected to the expansion slot.
Status of the board inserted in Slot1
Note
This display example shows a case where the DRX board is mounted on the front side and the HIF board is mounted
on the rear side.
Menu Image Item Description
*Slot1 Diag* 12/17
1&2: 1080/59.94I
3 :M1080/59.94I
HD CB:BAR 16:9(100%)
Front:DRX Power:OK
PLD Version:1.00 Done
Rear :HIF Power:OK
1 & 2 Output format of Output 1 & 2
3 Output format of Output 3
HD CB The output color bar signal
Front, Power Status of power supply to the board installed in option slot
1 and the board name
PLD Version PLD version of the board installed in option slot 1 and the
board name
Rear, Power Status of power supply to the rear board and board name
HDCU2500
3-7
