3-2-2. Settings of Entire System
The model name of the camera connected to the unit, the format setting, CCU output format setting, external reference
setting and return signal format setting are displayed.
Menu Image Item Description
*System Status* 1/17
Ref:HD Lock
Camera :HDC2500(HB)
1080/59.94I
HD Main:1080/59.94I
HD Conv:-------------
SD Conv:525/59.94I
RET1:1080/59.94I(PsF)
RET2:1080/59.94I(PsF)
RET3:1080/59.94I(PsF)
RET4:NTSC
Ref Reference signal format and lock status
Camera Model name of the connected camera
HD Main Return signal format
HD Conv HD up convert setting status
SD Conv SD up convert setting status
RET1 Return 1 return format selection status
RET2 Return 2 return format selection status
RET3 Return 3 return format selection status
RET4 Return 4 return format selection status
3-2-3. Status of Internal Boards
Names of boards mounted in front slots and self-diagnosis results of mounted boards are displayed.
Menu Image Item Description
2/17
** Diagnosis **
A:AT :OK 1:DRX OK
B:AVP :OK 2:DRX OK
C:DTX :OK 3:RC OK
Slot A to C Board names and self-diagnosis results of boards
Slot 1 to 3
3-2-4. Camera System Diagnostics
Page 1: System diagnostics 1
Menu Image Item Description
*System Diag 1/3* 3/17
Optical Condition
CAMERA OK
CCU OK
Fan Power OK
Timer 56H
CCU Power AC OK
SerialNo 00002002
CAMERA Camera light sensor level
CCU CCU light sensor level
Fan Power CCU power supply fan status
Timer Elapsed time since power-on
CCU POWER CCU power supply type and status
Serial No. CCU serial number
HDCU2500
3-4
