Sony HDCU2500 - Network Diagnostics

Page 2: System diagnostics 2
Menu Image Item Description
*System Diag 2/3* 4/17
CAMERA Cable Connect
Data OK
Power OK
RCP/CNU Cable Connect
Data OK
Power OK
CAMERA Cable Camera cable connection status
Data Camera data transmission status
Power Camera power supply status
RCP/CNU Cable This unit’s REMOTE connector cable connection
status
Data Data transmission status from a device connected to
this unit’s REMOTE connector
Power Power supply status to a device connected to this
unit’s REMOTE connector
Page 3: System diagnostics 3
Menu Image Item Description
*System Diag 3/3* 5/17
Intercom
CCU Private
CAMERA CH1 ENG
MIC OFF
CH2 PROD
MIC OFF
CHU MIC Gain Local
CH1 60 dB
CH2 60 dB
Intercom CCU CCU intercom selection status
CAMERA CH1 Camera intercom 1 selection status and camera
microphone status (When 1CH is selected via
the INTERCOM menu (C07), the PROD set-
ting cannot be changed.)
CAMERA CH2 Camera intercom 2 selection status and camera
microphone status
CAM MIC Gain Camera microphone circuit control status
CH1 Camera microphone circuit 1 amp gain status
CH2 Camera microphone circuit 2 amp gain status
3-2-5. Network Diagnostics
Page 1: Network diagnostics 1
Menu Image Item Description
*Network Diag 1/3* 6/17
MacAddress 00014A-xxxxxx
Auto Negotiation: ON
Auto MDIX : ON
Connect Speed : 100M
Duplex Mode : FULL
MDI/MDIX Select : MDIX
Link Status :OK
MacAddress CCU MAC address
Auto Negotiation Auto negotiation setting status
Auto MDIX Auto-MDIX setting status
Connect Speed Connection speed setting status
Duplex Mode Communication method setting status
MDI/MDIX Select Communications port wiring configuration selection status
Link Status LAN connection status
HDCU2500
3-5
