Sony HDCU2500 Maintenance Manual

1-7. Service Tools/Measuring Equipment List
1-7-1. Service Tools
Part No. Name Usage/Note
A-1153-700-A EX-982 board For extension of front boards
A-1153-701-A EX-983 board For extension of rear boards
A-1153-715-A EX-984 board For extension of the SDP-17 board
J-6480-010-A Alignment sleeve remover HC-001
For female optical connector (LEMO
®
DCC.
91.312.5LA or equivalent)
J-7120-220-A PLD download fixture PLD data download cable
— Cotton swab Commercially available, for cleaning optical con-
tact block (4 mm or less in diameter)
1-7-2. Measuring Equipment
Use the calibrated equipment or equivalent as listed below for the adjustments.
Equipment Type name
Digital oscilloscope (300 MHz or higher) Tektronix TDS460A or equivalent
SD waveform/Vector monitor Tektronix 1780R or equivalent (for NTSC)
Tektronix 1781R or equivalent (for PAL)
SD signal generator Tektronix TSG170A or equivalent (for NTSC)
Tektronix TSG271 or equivalent (for PAL)
Audio oscillator Tektronix SG-5010 or equivalent
Frequency counter Advantest TR5821AK or equivalent
HDCU2500
1-20
