8. Remove the six screws, and remove the PS-778D00 board.

PSW3 x 6

PS-778D00 board

PSW3 x 6

9. Install the removed parts by reversing the steps of removal.

4-2-5. Notes on Disassembling the Power Block Assembly (D00)

After the power block assembly (D00) was disassembled and parts have been replaced or repaired, extend the harnesses

and clamp them with harness clamps referring to the following three figures.

HDCU2500

4-10
