Connector Name Connector/Cable
VDA-64A board
• VBS 1, 2
• PIX OUT
• WF OUT
(BNC type)
1-564-742-11 PLUG, BNC or B-
B Cable assembly (1.5 m, option-
al)
VDA-64B board
• FRAME REF IN
• FRAME REF OUT
• PIX OUT
• WF OUT
(BNC type)
VDA-64C board
• VBS
• R/R-Y
• G/Y
• B/B-Y
(BNC type)
1-3-7. Note in Connecting CAMERA
Connector
It is recommended to clean the optical contact portions mentioned
below before connecting this unit to the camera.
For details on a cleaning method, refer to“1-14. Cleaning of
Connector/Cable”.
• CAMERA connector of this unit
• CCU connector of the camera
• Optical/Electrical cable
HDCU2500
1-9
