Sony HDCU2500 Maintenance Manual

Ref. No. Name Color Description Normal state
D103 POWER Green Lit when the power to the DTX-9 board has correctly started. —
RC-105 Board
D201
D3
D202
D203
D204
D205
D206
D207
D208
D209
D210
1
2
3
4
A
B
C
DE
F
RC-105 Board (Side A)
Ref. No. Name Color Description Normal state
D3 POWER Green Lit when the power to the RC-105 board has correctly star-
ted.
—
D201 1080 Green Lit when the Active-Line of the Main output is 1080-For-
mat.
*1
—
D202 720 Green Lit when the Active-Line of the Main output is 720P-For-
mat.
*1
—
D203 SD Green
Lit when the Main output is SD-Format.
*1
—
D204 P/PsF Orange
Lit when the Main output is Progressive video.
*1
—
D205 FC Orange Lit when the frame frequency converted signal is output
from the Main output.
*1
—
D206 60 Green Lit when the Main output is 1080-60i/59.94i or 720-60P/
59.94P.
*1
—
D207 50 Green
Lit when the Main output is 1080-50i or 720-50P.
*1
—
D208 30 Green
Lit when the Main output is 1080-30PsF/29.97PsF.
*1
—
D209 25 Green
Lit when the Main output is 1080-25PsF.
*1
—
D210 24 Green
Lit when the Main output is 1080-24PsF/23.98PsF.
*1
—
*1: Blinks when the format setting is defective.
HDCU2500
1-14
