Section 2
System Setup
2-1. System Connection
This unit can support input and output of multiple formats. It can also support various types of user’s format by installing
the optional circuit boards. The slots to be used and the switch setting on each board vary depending on the system to
be used.
Note
Regarding the installation of the optional boards, refer to “1-10. Option Board Installation Position”.
Model name Function Board name
(slot on the front side)
Board name
(slot on the rear side)
HKCU1001
SD Analog Interface Unit
• Composite video signal output EN-159A VDA-64A
HKCU1003
MULTI Interface Unit
• Composite video signal output
• Frame reference input/output
• Component video signal output
EN-159B VDA-64A
VDA-64B
VDA-64C
*1
HKCU2007
3G/HD SDI OUTPUT EX-
PANSION UNIT
• 3G-SDI/HD-SDI Output DRX-9 HIF-57
Note
*1: The VDA-64C board that adds the component video signal output function cannot be installed in HDCU2500.
HDCU2500
2-1
