Sony HDCU2500 Maintenance Manual

V24: BLACK SHADING
Menu Image Item Settings Description
<BLACK SHADING> → V24 TOP
[R] [G] [B] [M]
V SAW : 0 0 0
V PARA : 0 0 0
H SAW : 0 0 0
H PARA : 0 0 0
BLK SET: 0 0 0
BLACK : 0 0 0 0
MASTER GAIN: 0dB
AUTO BLACK SHADING
GAIN BOUNCE: OFF
V SAW R/G/B ±99
V PARA R/G/B ±99
H SAW R/G/B ±99
H PARA R/G/B ±99
BLK SET R/G/B ±99
BLACK R/G/B/M ±99
MASTER GAIN –3dB to +12dB
AUTO BLACK
SHADING
To execute:
Place the cursor at “AUTO
BLACK SHADING”, and turn
the CANCEL/ENTER lever to
the ENTER side.
To cancel:
Turn the CANCEL/ENTER lev-
er to the ENTER side during ex-
ecution.
GAIN BOUNCE ON/OFF
V25: WHITE SHADING
Menu Image Item Settings Description
<WHITE SHADING> → V25 TOP
[R] [G] [B]
V SAW : 0 0 0
V PARA : 0 0 0
H SAW : 0 0 0
H PARA : 0 0 0
WHITE : 0 0 0
AUTO WHITE SHADING
WHITE SHAD MODE: RGB
V SAW R/G/B ±99
V PARA R/G/B ±99
H SAW R/G/B ±99
H PARA R/G/B ±99
WHITE R/G/B ±99
AUTO WHITE
SHADING
To execute:
Place the cursor at “AUTO
WHITE SHADING” and turn
the CANCEL/ENTER lever to
the ENTER side.
To cancel:
Turn the CANCEL/ENTER lev-
er to the ENTER side during ex-
ecution.
WHITE SHAD
MODE
RB/RGB
V26: AUTO IRIS
Menu Image Item Settings
<AUTO IRIS> → V26 TOP
WINDOW : 1
IRIS LEVEL: 0
APL RATIO : 65
IRIS GAIN : 0
AUTO IRIS : OFF
WINDOW 1 to 6
IRIS LEVEL ±99
APL RATIO ±99
IRIS GAIN ±99
AUTO IRIS ON/OFF
HDCU2500
3-36
