1-6-2. Functions of Onboard Switches
AT-167A Board
S419
S413
S412
S420
S406
S407
S408
S409
S416
S103 S104
S101 S102
S403
S404
S410S405
S411
S418
1
2
3
4
5
A
B
C
DE
FGHJ
AT-167A Board (Side A)
Note
Do not change the setting of “Factory use” switch.
Ref. No. Name bit Description Factory setting
S101 PRTCT — Factory use ON
S102 DEBUG — Factory use OFF
S103 URA — Factory use OFF
S104 DEBUG — Factory use OFF
S403 H-Phase (STEP) — Factory use 8
S404 V-Phase — Factory use 8
S405 V-DLY — Factory use 0
S406 MODE1 1 to 8 Factory use OFF (ALL)
S407 TEST 1 to 4 Factory use OFF (ALL)
5 ON
6 to 8 OFF (ALL)
S408 MODE2 1 to 8 Factory use OFF (ALL)
S409 CCU-NO 1 to 8 Factory use OFF (ALL)
S410 HD-SD DLY — Factory use LINE-DLY
S411 SEQ1&SEQ2 — Switch depending on the waveform monitor to
be used.
+: PNP open collector output
–: NPN open collector output
+
S412 SYNC — Factory use SD
S413 10F-BB — Factory use OFF
S416 Co-AX/D-S-F1 — Factory use Fiber
S418 48V/50V/60V — Factory use 60
S419 720/Psf/I — Factory use INTR
S420 1001/RMT/1000 — Factory use REMOTE
