Section 5
Electrical Alignment
5-1. Preparations
5-1-1. Equipment Required
Measuring equipment
Equipment Type name
Digital oscilloscope (300 MHz or higher) Tektronix TDS460A or equivalent
SD waveform/Vector monitor Tektronix 1780R or equivalent (for NTSC)
Tektronix 1781R or equivalent (for PAL)
SD signal generator Tektronix TSG170A or equivalent (for NTSC)
Tektronix TSG271 or equivalent (for PAL)
Audio oscillator Tektronix SG-5010 or equivalent
Frequency counter Advantest TR5821AK or equivalent
Related equipment
Model name Description
HDC2400/2500 HD color video camera
MSU-1000/1500 Master setup unit
Tools
Name Usage/Note Part No.
EX-982 board Front-side extended board A-1153-700-A
EX-983 board Rear-side extended board A-1153-701-A
EX-984 board SDP-17 extended board A-1153-715-A
5-1-2. Notes on Adjustments
• Make sure all the measures have already been calibrated.
• Make sure “5-1-4. Initialization Settings” have already been finished.
• Make sure the adjustment of the HDC2400/2500 has already been finished.
• Types of the color bars to be output from the built-in synchronizing signal generator :
Signal format Y C
HD-SDI 100 % 100 %
SD-SDI (D1) 100 % 75 %
SD-Component-analog
(HKCU1001)
100 % 75 %
SD-Composite-analog
(HKCU1001)
75 % 75 % (SMPTE)
SD-Composite-analog
(HKCU1001)
100 % 75 % (EBU)
• To adjust this unit, extend each plug-in board. Before pulling out the boards, be sure to turn off the main power.
• Before starting adjustment, warm up for about 10 minutes.
• Before using the MSU-1000/1500, check the version of the ROM. For details, refer to Section “1-1. Checking the
ROM and Software Version ROM”.
HDCU2500
5-1
