Sony HDCU2500 Maintenance Manual

V06: GAMMA
Menu Image Item Settings
<GAMMA> → V06 TOP
[R] [G] [B] [M]
LEVEL : 0 0 0 0
COARSE : 0.45
GAMMA TYPE: 5
: BVW-400
GAMMA : ON
TEST : OFF
LEVEL R/G/B/M ±99
COARSE 0.90 to 0.35
GAMMA TYPE 0 to 8
Type Name
0 ----
1 ×3.5
2 ×4.5
3 CAMCORDER
4 ×5.0
5 BVW-400
6 SMPTE-240M
7 ITU-R709
8 FILM
GAMMA ON/OFF
TEST OFF/1/2
V07: BLACK GAMMA
Menu Image Item Settings
<BLACK GAMMA> → V07 TOP
[R] [G] [B] [M]
LEVEL : 0 0 0 0
RANGE : HIGH
: OFF
TEST : OFF
LEVEL R/G/B/M ±99
RANGE LOW/MID L/MID H/HIGH
ON/OFF
TEST OFF/1/2
V08: KNEE
Menu Image Item Settings
<KNEE> → V08 TOP
[R] [G] [B] [M]
K POINT: 0 0 0 0
K SLOPE: 0 0 0 0
KNEE : ON
KNEE MAX : OFF
KNEE SAT : 0 : OFF
AUTO KNEE : OFF
POINT LIMIT: 0
SLOPE : 0
K POINT R/G/B/M ±99
K SLOPE R/G/B/M ±99
KNEE ON/OFF
KNEE MAX ON/OFF
KNEE SAT ±99
ON/OFF
AUTO KNEE OFF/AUTO
POINT LIMIT ±99
SLOPE ±99
HDCU2500
3-31
