• VBS/R/G/B (VBS 1.0 Vp-p, 75 Ω )
3. WF OUT
• BNC type
• 0.714 Vp-p, 75 Ω (NTSC)
0.7 Vp-p, 75 Ω (PAL)
• ENC : 1.0 V p-p
1-3-4. Connector Input/Output Signals of
HKCU1003
Note
The VDA-64C board that adds the component video signal output
function cannot be installed in HDCU2500.
VDA-64A board
Output Signals
1. VBS 1, 2
• BNC type
• VBS 1.0 V p-p, 75 Ω
2. PIX OUT
• BNC type
• VBS/R/G/B (VBS 1.0 Vp-p, 75 Ω)
3. WF OUT
• BNC type
• 0.714 Vp-p, 75 Ω (NTSC)
0.7 Vp-p, 75 Ω (PAL)
• ENC : 1.0 V p-p
VDA-64B board
Input/Output Signals
1. FRAME REF IN
• BNC type
• HD: SMPTE 274M compliant
tri-level sync input, 0.6 Vp-p, 75 Ω
• SD: Black burst signal input, 0.286 Vp-p, 75 Ω
2. FRAME REF OUT
• BNC type
• Loop-through output or frame sync pulse output, 0.3 Vp-
p, 75 Ω, selectable
3. PIX OUT
• BNC type
• VBS/R/G/B (VBS 1.0 Vp-p, 75 Ω)
4. WF OUT
• BNC type
• 0.714 Vp-p, 75 Ω (NTSC)
0.7 Vp-p, 75 Ω (PAL)
• ENC : 1.0 V p-p
VDA-64C board
Output Signals
1. VBS OUT
• BNC type
• VBS 1.0 V p-p, 75 Ω
2. R/R-Y OUT
• BNC type
• R (100% white): 0.7 Vp-p, 75 Ω
• R-Y ( when outputting 75% color bar):
0.7 Vp-p, 75 Ω (NTSC, SETUP: ON)
0.525 V p-p, 75 Ω (PAL)
3. G/Y OUT
• BNC type
• G (100% white): 0.7 Vp-p, 75 Ω
• Y (100% white):
1.0 V p-p (Video : 0.714 V, synchronous 0.286 V,
NTSC), 75 Ω
1.0 V p-p (Video : 0.7 V, synchronous 0.3 V, PAL), 75
Ω
4. B/B-Y OUT
• BNC type
• B (100% white): 0.7 Vp-p, 75 Ω
• B-Y ( when outputting 75% color bar):
0.7 Vp-p, 75 Ω (NTSC, SETUP: ON)
0.525 V p-p, 75 Ω (PAL)
HDCU2500
1-7
