Brother GTX-4 Service Manual

6-78
Disassembly / Replacement / Adjustment
6-1-28. Replacement of filters of print head on white side
Disassembly
(1) Select the [Exchange Filter] from the Advanced menu and select the filter to be replaced. Then, turn off the power
following the on-screen prompts.
<IMPORTANT>
 Please note that the filters should be replaced one by one.
<TIPS>
 Ink installation should be performed after replacing the filters. If the ink level is low, make a new ink pouch available for use.
(2) Remove the four screws fixing the cartridge cover B on the right rear of the main unit to detach it.
(3) Take out the cartridge set at the portion whose filter is to be replaced, replace the white ink pouch with a capping
pouch, and then insert the cartridge into the main unit.
2
2
Print Position Adjust
Input Check
Output Check
Setting special work mode
Exchange Filter
Advabced Menu
White-3
White-2
White-4
White-1
Exchange Filter
