6
Cable clamp
This is used to put the cables together.
Filter cover and Fan filter
Waste ink tank
Fix the waste ink tank to the table leg or the like by using two
pieces of string, etc.
When the tank is fixed, insert the waste ink tube and the waste
ink tube fixing rubber.
IMPORTANT
The waste ink tube contained in the waste ink
tank should be cut down to around 1.6 to 2 in. (4
to 5 cm) remaining just inside the tank. Avoid
placing the waste ink tube horizontally as much
as possible, and be sure not to let it bend.
Otherwise the waste ink may have difficulty
flowing through the tube.
TIPS
Install the waste ink tank in the front, because it
must be emptied when the waste ink is full.
X0024
X0023
X0015
To Next Page
