6-117
Disassembly / Replacement / Adjustment
Procedures for returning the print head
In case it becomes necessary to return used print heads, follow the procedures indicated below:
(1) Place the print head removed from the carriage onto the nozzle protector attached to the new replacement.
(2) Attach fittings to the ink supply port on the removed print head.
(3) Lock the print head in place with the locking mechanism equipped on the nozzle protector and replace lid.
To Next Page
