Delta DVP-ES3 Series Hardware Manual

Chapter 5 CPU and Module Devices
5-17
5_
5.2.11 32-bit Counters (HC)
 Characteristics of the 32-bit counter
Item
32-bit counter
Type
Up/down counter
Up counter
High-speed counter
Number
HC0–HC63
HC64–HC199
HC200–HC255
Direction Counts up/down Counts up Counts up/down
Setting value
-2,147,483,648 to +2,147,483,647
Specification of the
counter setting value
The counter setting value can be either the constant or the value occupying two
data registers (32-bit).
Change of the current
value
The counter keeps counting even after the value of the counter matches the counter
setting value.
Output contact
The contact is ON when the value of the addition counter matches the counter
setting value.
The contact is reset to OFF when the value of the subtraction counter matches the
counter setting value.
Reset
When the RST instruction is executed, the current value is cleared to zero, and the
contact is reset to OFF.
Action of the contact
After the DCNT instruction scan is complete, the contact acts.
 32-bit general-purpose addition/subtraction counter
1. The difference between the 32-bit general-purpose addition counters and the 32-bit general-purpose subtraction
counters depends on the states of the special auxiliary relays SM621–SM684. For example, the counter HC0 is
an addition counter when SM621 is OFF, whereas HC0 is a subtraction counter when SM621 is ON.
2. You can use either the constant or the value in the data registers as the counter setting value, and this setting
value can be positive or negative. If you use the value in the data registers as the counter setting value, this
setting value occupies two consecutive registers.
3. For the general-purpose counter, the current value of the counter is cleared when power is lost. If the counter is
latching, the current value of the counter and the state of the contact before loss of power is retained. The
latched counter counts from the current value when power is restored.
4. If the counter counts up from 2,147,483,647, the next incremental value is -2,147,483,648. If the counter counts
down from -2,147,483,648, the next incremental value is 2,147,483,647.
5. This HC counter should work with DCNT instruciotn (API1004); below shows an example of common usage.
 32-bit high speed addition/subtraction counter
Refer to the instruction description of API1004 DCNT in DVP-ES3/EX3/SV3/SX3 Series Programming Manual for more
details.
