DVP-ES3/EX3/SV3/SX3 Series Hardware and Operation Manual

6-16

6.5.4

Basic Editing ─ Selecting a Network and Operation

Before you select an object in a network, press Esc on the keyboard, or click on the toolbar. After the

cursor appears as a small arrow, click the object in the network. The basic selection shows below.



Select the network



Select the input contact



Select the network



Select the output coil



Select the block

To select a group of devices, click a device and drag it to draw a frame around the group of devices. You can

also select the group of devices by clicking the first device, pressing Ctrl+B on the keyboard, clicking the last

device, and then pressing Ctrl+B on the keyboard. You must draw a frame around devices that are in the

same network, and the devices must be adjacent to one another. Input and output devices cannot be in the

same frame.

To select several networks, press and hold the Ctrl key on the keyboard and click the networks. You can also

select a range of networks by pressing and holding Shift on the keyboard, clicking the first network within the

range, and then clicking the last network within the range.
